I-station Gateway LONG RANGE is shipped preconfigured and ready for use. This high-performance wireless kit offers everything you need for robust industrial network connectivity. The central gateway provides a secure, carrier-grade communication hub protected by a rugged, weatherproof casing. It features multiple network options, including 4G cellular and Ethernet, to safely transfer data to the cloud. To extend the network’s reach, the included 3dBi omnidirectional fiberglass antenna screws directly onto the gateway using a heavy-duty N-connector, maximizing signal quality in harsh environments. The setup is powered by a compact 30W PoE injector, which sends both power and data over a single network cable, completely eliminating the need for complex, separate electrical wiring.
| Component | Key Feature | Specification |
| Gateway | Wireless Protocol | LoRaWAN (8 channels RX multi-SF) |
| Gateway | Backhaul Options | 4G Worldwide module with 3G/2G fallback & Ethernet |
| Gateway | Enclosure Rating | IP67-rated aluminum and polycarbonate casing |
| Antenna | Gain & Type | 3 dBi Omnidirectional Collinear |
| Antenna | Connection & Material | N-type Male connection / Heavy-duty fiberglass |
| PoE Injector | Power Output | 30 Watts |
| PoE Injector | Interface | Standard RJ45 Ethernet ports |
