Hikvision DS-2TP21-6AVF/W 160×120

The temperature screening handheld thermography camera, specially designed for skin-surface
temperature measurement. The 3.5-inch touch screen displays picture in picture of optical and
thermal view, fusion of both channels. It helps you quickly find the exception according to accurate
temperature measurement of high temperature targets in the environment.

Datasheet DS-2TP21-6AVFW

Hikvision Thermal Overview

Login to see prices
SKU: DS-2TP21-6AVF/W Category: Tags: , ,

Hikvision DS-2TP21-6AVF/W

Thermographic Handheld Camera

  • 160 × 120 resolution (thermal), and 8 MP resolution (optical)
  • DDE, 3D DNR, and adaptive AGC
  • 640 × 480 resolution 3.5” LCD touch display
  • Up to five hours continuous running

Thermal Module

  • Image Sensor VOx Uncooled Focal Plane Arrays
  • Resolution 160×120
  • Pixel Interval 17μm
  • Response Waveband 8μm to 14μm
  • NETD Less than 40 mK (@25°C,F#=1.1)
  • Focal Length 6.2mm
  • Focus Mode Manual
  • Field Of View 25° × 18.7°
  • IFOV2.74 mrad
  • Image Frequency 25 hz
  • Aperture F 1.1

Thermography

  • Rules Max. Temperature; Min. Temperature; Center Temperature; Custom Point/Line/Area Thermography
  • Thermographic Range From -20°C to +550°C (-4°F ~ +1022°F)
  • Accuracy Max (±2°C, ±2%)
